Apacer SS220-CFast

简介

Featuring CorePower technology, Apacer’s SS220-CFast is a well-balanced CFast card with compact form factor and great performance. This new flash memory card comes with SATA 6.0 Gbps interface for higher performance and is compliant with standard SS220-CFast specifications. SS220-CFast 2.0 consists of SATA-based 7-pin signal segment and 17-pin for power and control purposes. It can offer moderate capacity and decent data transfer performance. For power efficiency, this new flash memory card leverages the technological benefits of SATA Revision 3.1 specifications, including Device Sleep. That will greatly reduce power consumption when the device is not in operating mode. For data integrity, the SS220-CFast card is built with ECC engine correcting up to 40-bit. Together with its small form factor nature, Apacer SS220-CFast 2.0 is definitely the ideal solution to replace conventional PATA-based CompactFlash for applications in industrial computing systems, mobile computers and video processing instruments.

参数

型号SS220-CFast

介面SATA 3.0 (6Gb/s)

接头(7+17) pin male

板型CFast

NAND 颗粒SLC

容量8GB~64GB

外接DRAMYes

读取速度(MB/sec)Up to 520

写入速度(MB/sec)Up to 455

ECC侦错功能Built-in 40-bit per 1K bytes BCH ECC

标准作业温度(°C)0 ~ + 70

最高作业温度(°C)-40 ~ + 85

储存温度(°C)-40 ~ + 100

H/W Write ProtectYes

冲击耐力50G (complied with MIL-STD810)

震动耐力15G (complied with MIL-STD810)

电压3.3 V ± 5%

用电量"Active mode: 570 mA & Idle mode: 75 mA

尺寸42.8 x 36.4 x 3.6 (mm)

MTBF (小时)>2,000,000

技术特点Page Mapping / 宽温 / 热传感器 / S.M.A.R.T. / 擦除 / 写保护

应用云计算 / 车载 / 嵌入式和IPC / 国防 / 游戏 / 保健
