| Module Name | 2.5” SATA SSD 3ME4 |
| Interface | SATA III 6.0 Gb/s |
| Flash Type | MLC |
| Capacity |
8GB~256GB |
| Sequential R/W (MB/sec, max.) | 530/210 |
| Max. Power Consumption | 0.8 W (5V x 160 mA ) |
| Max. Channels | 2 |
| Thermal Sensor | Y |
| External DRAM Buffer | N |
| iCell | N |
| MTBF | >3 million hours |
| ATA Security | Y |
| Dimension (WxLxH/mm) | N |
| Storage Temperature | -55°C ~ +95°C |
| Operation Temperature |
Standard Grade: 0°C ~ +70°C; Industrial Grade: -40°C ~ +85°C |
| S.M.A.R.T. | Y |
| Dimension (WxLxH/mm) | 69.85 x 100.10 x 6.9 |
| Vibration | 20G@7~2000Hz |
| Shock | 1500G@0.5ms |
| Operation Temp. |
16GB |
64GB |
64GB |
128GB |
256GB |
|
Standard Grade (0°C ~ +70°C) |
DES25- 08GM41BC1SC |
DES25-16GM41BC1SC DES25-16GM41BC1DC |
DES25-32GM41BC1DC | DES25-64GM41BC1DC | DES25-B56M41BC1DC |
|
Industrial Grade (-40°C ~ +85°C) |
DES25- 08GM41BW1SC |
DES25-16GM41BW1SC DES25- 16GM41BW1DC |
DES25-32GM41BC1DC | DES25-64GM41BW1DC | DES25-B56M41BW1DC |
